Nevada 27.5 1.7 SRAM

$749.99 USD
Size
Color: Cyan

This product is unavailable

Description

A staple in the Fuji mountain-bike lineup, available in 29" or 27.5" wheel sizes, the Nevada combines a tried and true hardtail frame and solid components to take your off-road adventures to the next level.

Shipping and Returns

SHIPPING

All non-bike items and a limited number of bike models have the option to ship to home. All other bikes ordered online will be delivered to your chosen local authorized Fuji dealer.

SHIP TO HOME RETURNS

Item(s) in new, unassembled, unused condition and with all original packaging, hangtags, and parts will be eligible for a refund when returned within 30 days of purchase. Return shipping fees apply.

*More Details

SHIP TO STORE RETURNS

Bicycles can be returned at time of pick-up only. After leaving the store with your assembled bicycle the sale is final. It’s up to the seller you purchased from to initiate the return. Restocking fee may apply.

*More Details

You may also like

Nevada 27.5 1.5

$849.99 USD

Nevada 27.5 1.7

$749.99 USD

Nevada 27.5 1.9

$649.99 USD
Technical Specifications
  • Sizes

    XS, S, M, L

    Color(s)

    Satin Gray, Cyan

    Frame

    Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle

    Fork

    SR Suntour SF19-XCT30-HLO-DS-27.5, hydraulic lockout, 100mm

    Crankset

    Prowheel, 42/34/24T

    Bottom Bracket

    Sealed cartridge bearing

    Pedals

    Resin platform

    Front Derailleur

    Microshift FD-M20

    Rear Derailleur

    SRAM X4

    Shifters

    SRAM X4, 3 x 8-speed

    Cassette

    Sunrace CSM66, 11-34T

  • Chain

    KMC HV700

    Wheelset

    WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes

    Tires

    WTB Ranger Comp, 27.5" x 2.25", 27tpi

    Brakeset

    Tektro HD-M275, 180/160mm rotors

    Brake Levers

    Tektro HD-M275

    Headset

    1 1/8" sealed bearings

    Handlebar

    Fuji riser bar, alloy, 15mm rise, 710mm

    Stem

    Fuji, forged aluminum, +/-6°

    Grips

    Fuji Performance Grip

    Saddle

    Fuji Performance Saddle

    Seat post

    Fuji, alloy, 30.9mm

*Specifications are subject to change without notice
Geometry
SizeXSSML
Bike Size13"15"17"19"
ASeat Tube, Center To Top310370420470
CTop Tube, Effective562581601629
DHead Tube Length95100110120
ESeat Tube Angle73°73°73°73°
GHead Tube Angle69.5°69.5°69.5°69.5°
HChainstay Length440440440440
IWheelbase1068.5108711091137
JBottom Bracket Drop45454545
KFork Offset 42424242
MStack596600610619
NReach380397415440
OStandover737767795823
Stem40454545
Handlebar Width710710710710
Crank170170175175
Wheel Size27.5"27.5"27.5"27.5"
Seat Post Diameter30.930.930.930.9
